R502Dual USB-A (C9) for Dual-interface Smart Card Reader
Buy R502Dual USB-A (C9) Dual-Interface Smart Card Reader – Contact & Contactless | CCID | ISO 7816 | ISO 14443
R502Dual USB-A (C9) Dual-Interface Smart Card Reader for Secure Authentication & Payment Systems
The R502Dual USB-A (C9) Dual-interface Smart Card Reader is a high-security contact and contactless smart card reader designed for global smart card deployments, the R502 reader supports ISO 7816 contact cards and ISO 14443 contactless cards, including MIFARE® and FeliCa®, making it ideal for PKI authentication, e-Government, e-Banking, EMV payment, and access control systems.
Built on a CCID driver architecture and fully compliant with PC/SC standards, the R502Dual USB-A smart card reader delivers plug-and-play compatibility across Windows, Linux, macOS, UNIX, and Android (OTG) environments. Its high-security chipset, firmware encryption, and anti-reverse engineering mechanisms ensure maximum data protection for mission-critical applications.
Why Buy the R502Dual USB-A (C9) Dual-Interface Smart Card Reader?
Organizations worldwide choose to buy R502Dual C9 smart card reader for its security, reliability, and interoperability across international infrastructures.
Key Advantages
- Dual-interface smart card reader (contact + contactless)
- USB-A connectivity for universal desktop and terminal compatibility
- CCID & PC/SC compliant – no proprietary drivers required
- Supports EMV2000 Level 1 for financial and payment environments
- Firmware upgradable with encrypted protection
- Designed for high-security authentication and identity systems
Global Use Cases & Applications
The R502Dual USB-A smart card reader is widely deployed across regulated and security-sensitive industries:
Core Applications
- e-Government & National ID systems
- e-Banking & Financial Institutions
- EMV e-Payment terminals
- e-Healthcare & medical identity
- e-Passport & border control
- Network access control & logical access
PKI & Identity Applications
- Digital signature creation
- Strong user authentication
- Secure identification & credential verification
Technical Features – R502Dual USB-A (C9)
- USB 2.0 Full Speed smart card reader
- Fully compliant with PC/SC and CCID standards
- Supports ISO 7816 T=0 and T=1
- Supports Class A, B, and C smart cards
- Built-in high-performance contactless antenna
- Contactless frequency: 13.56 MHz
- Supports ISO 14443 Type A & Type B
- Compatible with MIFARE Classic S50/S70, Ultralight C & FeliCa
- EMV2000 Level 1 certified
- Firmware encryption with anti-reverse analysis
- Open UID (User ID) functionality
- Secure firmware upgrade support
Detailed Specifications – R502Dual USB-A (C9) Smart Card Reader
Hardware & Electrical
- Model / Casing: R502Dual USB-A (C9)
- Interface: USB 2.0 Full Speed
- Connector: USB Type-A
- Power Supply: USB 5V DC
- Current Consumption: <100 mA (without card)
Contact Smart Card
- Standards: ISO 7816-1/2/3
- Protocols: T=0, T=1
- Card Class: 1.8V / 3V / 5V
- Card Size: ID-1 (full-size)
- Clock Frequency: 4 MHz
- Read/Write Speed: 10,753 – 688,172 bps
- Durability: 300,000 insertions
Contactless Smart Card
- Standards: ISO 14443 Type A & B
- Frequency: 13.56 MHz
- Data Rates: 106 / 212 / 424 / 848 kbps (card dependent)
- Operating Distance: Up to 5 cm
Physical & Environmental
- Dimensions: 120 × 80 × 25.6 mm
- Weight: 128 g
- Material: ABS + PC
- Cable: Fixed, 1.5 m
- LED Indicators: Red, Green, Blue
- MTBF: 500,000 hours
Environmental Conditions
- Operating Temperature: 0°C to 60°C
- Storage Temperature: -20°C to 85°C
- Humidity: ≤90% (non-condensing)
Security Architecture
The R502Dual USB-A (C9) smart card reader is engineered for high-security deployments:
- Hardware short-circuit protection
- Thermal and over-voltage protection
- Electrostatic discharge (ESD) prevention
- High-security certified chipset
- Firmware cannot be read or extracted
- Encrypted firmware architecture
- Anti-reverse engineering protection
- Secure encrypted firmware upgrades
Standards & Certifications
- ISO 7816 Smart Card Standard
- ISO 14443 Contactless Standard
- MIFARE® Standard
- FeliCa® Standard
- EMV2000 Level 1
- USB 2.0
- PC/SC
- CCID
Regulatory Certifications:
CE | FCC | RoHS | EMV Level 1 | LTIC | BSMI | U
Operating System Compatibility
- Windows 2000 and later
- Linux
- macOS X
- UNIX
- Android (OTG supported)
Customization & Warranty
- OEM logo branding
- Custom packaging
- Firmware customization
- Color customization options
- Warranty: 1 Year
Buy R502Dual USB-A (C9) Dual-Interface Smart Card Reader – Global Supply
The R502Dual USB-A (C9) Dual-interface Smart Card Reader is an optimal choice for organizations seeking a secure, certified, and globally compatible smart card reader for authentication, PKI, and payment systems.
Whether you are deploying solutions across North America, Europe, APAC, or the Middle East, this reader delivers enterprise-grade security, long-term reliability, and international compliance.
Request pricing, bulk orders, or OEM customization today.
