JCOP4 P71 SeclD Payment Dual Interface Support SHA 256 ECC 521 RSA 4096 Smart Card JavaCard J3R150 J3R180 J3R200
JavaCard J3R200
- Color: White
- Material: Banking Grade PVC
- Memory: 85K
- Chip: Original J3R200
- Standard: Java Card 3.0.5 Classic, Global Platform 2.3
- Total NVM Size: 210K
- User NVM Size: 85K
- Total RAM Size: 8K
- User RAM size: 3K
- Algorithm: RSA4096, SHA256, ECC521
- Protocol: ISO7816, ISO14443
- Size: ISO 7810 (85.60*53.98mm) /customized
- Special Features: DESFire EV2 4K
- Communication Interface: ISO7816, ISO14443
JavaCard J3R200 Smart Card – JCOP4 P71 Secure Dual Interface Banking & Payment Card
JCOP4 P71 SeclD Payment Dual Interface Support SHA 256 ECC 521 RSA 4096 Smart Card JavaCard J3R150 J3R180 J3R200
Java Card J3R200 smart card with JCOP4 P71 secure chip supporting RSA-4096, ECC-521 and dual interface NFC technology for banking, EMV payment, PKI authentication and digital identity systems.
Understanding Smart Card Java Card J3R200 Features
The Java Card J3R200 offers advanced capabilities for secure transactions, supporting both dual interface functionality and enhanced cryptographic algorithms. With its robust specifications including SHA 256, ECC 521, and RSA 4096, this smart card is designed to meet the demands of modern payment systems. The Java Card J3R200 is an ideal choice for developers seeking a reliable and secure solution for their applications. Its compatibility with various platforms further enhances its versatility in the evolving landscape of digital security.
Most popular in Banking Application Smart Card
The Smart Java Card J3R200 is becoming increasingly popular for secure payment solutions. The Smart Java Card J3R200 features enhanced capabilities that make it suitable for various applications. By utilizing the Smart Java Card J3R200, developers can ensure high levels of security. The versatility of the Smart Java Card J3R200 enhances its appeal in digital security.
Applications utilizing the Smart Card Java Card J3R200 can take advantage of its advanced features. With the Smart Card Java Smart Card J3R200, secure transactions can be achieved effortlessly. For developers, the Smart Card Java Card J3R200 provides a reliable framework. The Smart Card JavaCard J3R200’s dual interface capability streamlines payment processes.
Security is paramount when using the Smart Card JavaCard J3R200 for transactions. Innovative solutions can be developed with the Smart Card JavaCard J3R200 in mind. The Smart Card JavaCard J3R200 is a game changer in the field of secure payments. Explore the benefits of the Smart Card JavaCard J3R200 in your next project.
Specification
The functions marked * are not supported by default. If you need these functions, please contact us before placing order.
If you don’t need the card to support DESFire EV2 4K, the user available NVM Size can be up to 169K.
| Model Name | JCOP J3R200 / J3R180 |
| OS Certification | FIPS 140-2 Level 3 |
| CC EAL6+ | |
| Chip Certification | CC EAL6+ |
| Secure box | Yes |
| CPU | 8bit |
| Physical Storage | |
| NVM Type | |
| Total NVM Size | 210K |
| Total RAM Size | 8K |
| User NVM Size | 85K |
| User RAM size | 3K |
| Algorithm | |
| RSA 2048 | Yes |
| RSA 4096 | Yes |
| AES | Yes |
| SHA-1 | Yes |
| SHA-256 | Yes |
| SHA-384 | Yes |
| SHA-512 | Yes |
| MD5 | No |
| 3DES (ECB, CBC) | Yes |
| KOREAN SEED | Yes |
| ECC FP | 160 bits to 521 bits |
| Standard Compliance | |
| Java Card™ 3.0.5 | Yes |
| Java Card™ 3.0.4 | Yes |
| GlobalPlatform 2.3 | Yes |
| GlobalPlatform 2.2.1 | Yes |
| EMV ICC Specification for Payment Systems 4.3 | Yes |
| EMV Contactless Specifications for Payment Systems (Book D) 2.6 | Yes |
| EMVCo | Yes |
| Communication Protocol | |
| ISO7816 T=0* | No(Customizable) |
| ISO7816 T=1 | Yes |
| ISO14443 T=CL Type A | Yes |
| ISO14443 T=CL Type B | No |
| Contactless VHBR | 3.2Mbits/s |
| Mifare* | No (Customizable) |
| DESFire EV2 4K | Yes |
| JCRE Features | |
| APDU Buffer Size | 261 bytes to 2048 bytes |
| Transaction Size | 2048 up to 64K |
| Extended APDU | Yes |
| Logical Channels | 1(Default) / 4* |
| GP Secure Channel Protocol | SCP01* / SCP02*/ SCP 03(Default) |
| Garbage Collector | Yes |
| Applet deletion | Yes |
| Product Configurations – Add Ons(Optional) | |
| Module | Match On Card(MOC) ID3 Neurotechnology* |
| MIFARE DESFire EV2 4K | |
| MIFARE Plus EV1 4K* | |
| Application* | PIV |
| FIDO | |
| OTP | |
| ChipDoc Suite | |
| eDoc Applet Suite | |
| MasterCard M/Chip | |
| VISA VSDC2.9 | |
| CPA1.0 | |
| DPAS v.10 | |
| AMEX 4.4/Expresspay 4.3 | |
| Customization | |
| Feature | Dual Interface,Contact,Contactless |
| Card Printing | 4/6 colours Offset Printing,UV Printing |
| Card Surface Process | Glossy Finish, Matte Finish, Other Card Processing Technology |
| (Only available for Offset Printing ) | |
| Magnetic Stripe | Hi-Co, Lo-Co |
| Others | ATR |
| SIM-size Cutting | |
| Jave Token -Java Card in USB Key Format | |
| One Time Password Card | |
| Application | |
| e-Government, Banking and Finance, Public Transportation, Access Control, Mobile, Loyalty Card, PIV, FIPS | |
| Customized support | Customized logo |
What is JavaCard J3R200 and how does it relate to JCOP4 P71 SeclD Payment Dual Interface Support?
JavaCard J3R200 is a platform that enables the development of secure applications on smart cards. It supports JCOP4 P71 SeclD Payment Dual Interface, allowing for enhanced security features such as SHA 256 encryption, ECC 521, and RSA 4096 for secure payment transactions.
How does the dual interface capability of JavaCard J3R200 enhance payment security?
The dual interface capability of JavaCard J3R200 allows secure communication through both contact and contactless methods, providing flexibility and convenience. This feature, combined with strong cryptographic support like SHA 256 and RSA 4096, ensures that payment transactions are secure against potential threats.
Can I use JavaCard J3R200 for applications beyond payment systems?
Yes, JavaCard J3R200 is versatile and can be utilized for a variety of applications beyond payment systems, including secure identity verification, access control, and digital signatures, thanks to its robust security features and support for advanced cryptography.
Buy Buy JavaCard J3R200 – Most popular in Banking Application Smart Card
JavaCard J3R150 / J3R180 / J3R200 Banking Application Smart Card. The JCOP4 P71 platform supports Java Card 3.0.5 and GlobalPlatform 2.3, enabling multiple secure applets for payment, ID, and authentication.
