bR500 bluetooth contactless smart card reader
bR500 bluetooth contactless smart card reader for Bluetooth Card Reader Card Reader – Bluetooth 4.2 BLE NFC Contactless Mobile Smart Card Reader BR500 – C45FC
We provides bR500 Bluetooth Contactless Smart Card Reader which is a CCID and PCSC standard product, the product is developed based on ISO 14443 standard, which supports Type A and Type B cards, extended APDU is also supported. bR500 can be used on iOS, Android, PC platforms. The product is compact, light and easy to operate, with Bluetooth Card Reader low power consumption design to save battery, and using latest contactless technologies to support the world-wide range of commonly used NFC cards. bR500 Bluetooth Contactless Smart Card Reader is a card reader hardware which requires a software to communicate with.
WE provide library and graphical user interface that allow user to all functions for secondary development. For mobile platforms, customer can develop their own application based on our SDK. For PC platforms, bR500 Bluetooth Contactless Smart Card Reader is fully compatible through a traditional USB cable (Micro USB cable included in package).
For using bR500 Bluetooth Contactless Smart Card Reader with Bluetooth connection on PC platforms, an extra Bluetooth CCID driver is required. bR500 Bluetooth Contactless Smart Card Reader suites customers where security concerns are the most salient and satisfies the demand for a flexible solution for ID authentication, e-commerce, e-payment, information security and access control.
Bluetooth 4.2 BLE NFC Contactless Mobile Smart Card Reader BR500 – C45FC
Features:
-Support iOS / Android / Linux / Mac OS X / Windows
-Compliant with EMV Level 1
-Support ISO-7816-1/2/3 T=0 and T=1 Protocol
-Support ISO-7816 Class A, B and C Cards
-Compliant with PC/SC, CCID Standards
-Provide third party development library
-MFI specified
-USB 2.0 Full Speed Device
-Support auto-PPS
More Features:
- Make your workflow wireless, full support of BLE (Bluetooth Low Energy)
- World’s lightest Bluetooth reader with a compact design, the BLE reader is compact enough to be hung on the neck as easily as an employee badge
- Market’s first CCID Bluetooth driver on Windows, enabling the BLE reader to work with PC wirelessly
- High-security hardware design
- Worldwide certifications make the reader an universal product on both functionality and performance
- Integrated low power feature, extends battery life by automatically turning off in 3 minutes after last data communication
Specification
| Product name | bR500 | ||
| Casing Model | C45FC | ||
| Basic Parameter | Bluetooth Interface | Bluetooth 4.2 | |
| Host Interface | USB Type C(CCID Standard) | ||
| Transmission Speed | 12Mbps (USB 2.0 Full Speed) | ||
| Extended APDU | Supported | ||
| Contactless | Build-in antenna | ||
| Smart Card Interface Speed | 106kbps-424kbps | ||
| Smart Card Clock Frequency | 13.56MHz | ||
| ISO 14443 Type A and Type B, Mifare© Protocol, Felica® protocol | |||
| Support OS | Win2000+/Linux/MacOS X/UNIX/Android(4.3+)/iOS(4.0+) | ||
| Certificate | CE/FCC/RoHS/EMV Level 1/LTIC/BSMI/NFC Forum/TELEC/Bluetooth© Smart | ||
| Physical Parameter | Material | PC | |
| Weight | 31g | ||
| Status Indicator | Blue, Red, Yellow, Green | ||
| Connector Cable | 0.8m | ||
| Color | Black | ||
| Dimension | 91 * 63 * 8mm (L*W*H) | ||
| Work Environment | Power supply | USB port 5V DC | |
| Working current | < 50mA without card plugged | ||
| Working Temperature | 0°C ~ 60 °C | ||
| Storage Temperature | -20°C ~ 85°C | ||
| Humidity | ≤90%(non-condensed) | ||
| Standard | Card Reader Standard | ISO 14443 Standard | |
| Felica Standard | |||
| Mifare © Standard | |||
| EMV Level 1 Standard | |||
| CCID Standard | |||
| PC/SC Standard | |||
| USB 2.0 Standard | |||
| API Standard | PC/SC Lite/WINSCARD API | ||
| Security | Physical Security | Short circuit and thermal protection/over-voltage protection | |
| High security level chipset | |||
| electrostatic prevention | |||
| Firmware Security | Firmware encryption mechanism | ||
| Firmware upgradability in encryption | |||
| Firmware cannot be read out | |||
| Anti-reverse analysis | |||
